Yarn Reinforced Polyester Pipe-wrapping Mat

Yarn Reinforced Polyester Pipe-wrapping Mat

Yarn Reinforced Polyester Pipe-wrapping Mat Yarn Reinforced Polyester Pipe-wrapping Mat is made of polyester mats on both sides, reinforced by fiberglass yarn in the middle. This mat is often used as excellent material for Pipe Wrapping, as well as substrate for APP or SBS modified bitumen...

Product Details



Yarn Reinforced Polyester Pipe-wrapping Mat is made of polyester mats on both sides, reinforced by fiberglass yarn in the middle. This mat is often used as excellent material for Pipe Wrapping, as well as substrate for APP or SBS modified bitumen membrane. Because of fiberglass yarn reinforcement, this mat has high tensile strength, so that it can bear faster speed of bitumen membrane machine.


Hot-Sale-Pipe-Wrapping-High-Quality-Fiberglass-Surfacing-Tissue-Mat (1)

Hot-Sale-Pipe-Wrapping-High-Quality-Fiberglass-Surfacing-Tissue-Mat (1)

Hot-Sale-Pipe-Wrapping-High-Quality-Fiberglass-Surfacing-Tissue-Mat - Features:

High resistance on temperature changes;

Bears faster speed of bitumen membrane machine;

Increases the tensile strength and tear strength of waterproofing bitumen membrane;

Extends the service life of waterproofing bitumen membrane and road.

Fiber Dispersed Uniformly

High Strength, Good Flexibility

Easy to Immerse into Bitumen and Coal-tar

Good Anti-permeability and resistance to

Environmental Media


Application:

Pipe Wrapping; Substrate for APP or SBS modified bitumen waterproof membrane.

downLoadImg



Technical data:



Product Code

Unit weight

PYP125-45X2

PYP135-50X2

PYP175-70X2

Product


polyester mat + fiberglass yarn + polyester mat



Total unit weight

g/m2

125

135

175

Polyester mat weight

g/m2

90

(45x2)

100

(50X2)

140

(70x2)

Yarn space

mm

5

5

5

Yarn No.

Tex

68

68

68

Tensile strength MD

N/5cm

500

500

500

Tensile strength CD

N/5cm

150

165

210

Roll width

mm

1002

1002

1002

Roll length

m

1000

950

700

Paper Core Dia

mm

76/150

76/150

76/150

Loading capacity

rolls/40’container

114

114

114



Packing & Delivery

Wrapped with shrinkage flim, then packed on the pallet.

  1. Roll packaging: PE plastic film.

  2. Pallet packaging: Pallets should NOT be stacked in more than 2 layers.
    Pallet is free of fumigation, fumigation certificate is available.


Storage
Unless otherwise specified, Chopped Strand Mat should be stored in a dry, cool and rain-proof area. It is recommended that the room temperature and humidity should be always maintained at 15ºC~35ºC and 50%~75% respectively.


1614650976(2)


Payment
LC, T/T, CAD, PAYPAL, WESTERN UNION, ETC.

After sales service
Nanjing EFG CO., LTD tracks cargo of every shipment till customer uses the fibreglass mat, and offer any help for customer's demand in any time.

Technical support
If customer meets any problem about technic, Nanjing EFG CO., LTD will supply relative knowledge to help customer find the best solution, and can send technician to customer's factory for guiding if necessary.
