Ceramic Fiber Mat for Auto Heat Insulation System

Ceramic Fiber Mat for Auto Heat Insulation System

TLF-970 series product is a basic type of high-performance insulation mat and is cost-effective. The series product is made of high-performance refractory ceramic fiber which has been purified by water and covered by an organic binder.

Product Details

Product description

TLF-970 series product is a basic type of high-performance insulation mat and is cost-effective. The series product is made of high-performance refractory ceramic fiber which has been purified by water and covered by an organic binder. TLF-970 series product exhibits excellent performance in the thermal insulation of the fire when the temperature is less than 12600C.


The flexibility of TLF-970 is excellent, bent nearly 180 degrees without crack. TLF-970 is easy to wrap or shape.

TLF-970 is mainly applied in the exhaust system insulation, chassis insulation, thermal protection of the engine, lithium battery separator, and new energy vehicle battery passive fire protection.


In addition, to meet the needs of automotive insulation fire, TLF-970 can be used in a variety of industrial insulation, electrical fire insulation, and fire protection.

This product can be used as a motor vehicle, electric heater protection, household electrical insulation, metal cladding gasket, thermal insulation in the petrochemical industry, transmission line protection, welding protection, sound insulation, thermo-shield, and thermocouple protection.

7E7A31017E7A3104_

Characteristics

Lightweight, small bending radius;

Excellent thermal stability;

Excellent insulation capability;

Good dielectric properties;

Low thermal conductivity and low heat capacity;

Excellent flexibility, easy to shape;

Non-hydrophilic material, acid-alkali corrosion;



Specifications

Type                           TLF-970 -256           TLF-970 -320               TLF-970 -512

Basis weight (g/m2)   256                          320                               512

Thickness ( mm)         1.6                           2                                   3.2    (thickness measured at 0.725kpa pressure)

Fiber index (%)           55-70                      55-70                            55-7



Products composition

Alumina-Silica Fiber     90-97%

Binder                           3-9%



Technical data

Item

 TLF-970- 256

TLF-970 -320

TLF-970- 512

Loss on ignition(LOI)@800℃ (%)

3~9

3~9

3~9

Classified temperature (℃)

1260

1260

1260

Temperature limit (℃)

1050

1050

1050

Density (kg/m3)

160

160

160

Basis weight(g/m2)

256

320

512

Minimum bending radius(

≥3

≥5

≥5

Tensile strength (Kpa)

≥110

≥110

≥ 110

Thermal conductivity @Room temperature W/(M*K)

< 0.035

< 0.035

< 0.035

@400℃

<0.1

<0.1

<0.1

@800℃

<0.18

<0.18

<0.18

Remark: 1. The technical data above is for reference only

 2. Any special size can also be supplied according to customers' request

16558805338911655879056671



Packing & Loading

1. Roll packaging: PE plastic film.

2. Pallet packaging: Pallets should NOT be stacked in more than 2 layers.

    The pallet is free of fumigation, fumigation certificate is available.


Delivery

The product will be loaded into a container in the factory. Then be delivered to the seaport, and finally shipped to the Customers' port by MSK, MSC, CMA, COSCO, YANG MING, APL,  etc.



Storage

This product should be stored in a dry, ventilated, rainproof place, with temperatures from 5℃to 35℃ and humidity between 35% and 65%. It is recommended to be kept in a safe package when not used to avoid dampness.



Customization

The product in the above table is the standard type Nanjing EFG CO., LTD is delivering to customers. If the customer wants it in specific unit weight, tensile strength, roll width, and roll length, Nanjing EFG CO., LTD can produce fiberglass mat as per the customer’s requirement, and offer tailored service to customers from different countries.


Payment

LC, T/T, CAD, PAYPAL, WESTERN UNION, ETC.


Our Services

Nanjing EFG CO., LTD tracks the cargo of every shipment till the customer uses the fiberglass mat, and offers any help for the customer’s demand at any time.

If the customer meets any problem with technic, Nanjing EFG CO., LTD will supply relative knowledge to help the customer find the best solution, and can send a technician to the customer's factory for guidance if necessary.

7E7A32607E7A3229
